E103-W07 is a set of network protocols based on Wi-Fi protocol. ESP-MESH allows a large number of devices (hereinafter referred to as nodes) distributed in a large area (indoor and outdoor) to be connected to each other in the same WLAN (wireless local area network). It is an efficient and reliable way to connect multiple nodes across wide areas to form a single communication network. ESP-MESH ensures a fast, secure, and stable connection with low latency and energy consumption.
Brand Name:EBYTE
Origin:Mainland China
Condition:New
Type:Drive IC
Model Number:E103-W07
Operating Temperature:-40℃-85℃
Package:SMD
Type:WIFI Mesh AD Hoc Network Module
Antenna:IPEX/PCB
| Main parameter | Performance |
| Working channel center frequency range |
2412~2484MHz |
| Wi-Fi |
Protocol IEEE802.11b/g/n |
| Antenna type |
PCB,IPEX Antenna |
| Transmit Power | 20dBm |
| Distance (With router @Mercury MW305R) |
200m |
| Distance (Between modules) |
100m |
|
Recommended working temperature（℃） |
–40~85 |
| Power pin voltage（V） |
3.0~3.6 |
| humidity(%RH) |
85 |
| Peak current(mA) |
400 |
| Average current(mA) |
100 |
