LoRa Wireless Module
Industrial LoRa Wireless Modules: Long-Range & Low-Power IoT Connectivity
Ebyte offers a specialized portfolio of high-performance LoRa wireless modules designed for robust and secure data transmission. Operating across global sub-GHz bands (433MHz, 868MHz, 915MHz) and 2.4GHz, our modules leverage Semtech’s advanced spread-spectrum technology to provide superior link budgets and exceptional interference immunity for long-range RF communication.
- Advanced Chipset Integration: Our series integrates industry-leading silicon, including the E22 series (SX1262) and the cost-effective E220 series (LLCC68), delivering communication distances of up to 10km+ with high receiving sensitivity.
- Versatile Hardware Interfaces: We provide flexible integration options including SPI modules for deep hardware customization and UART (TTL) modules with transparent transmission protocols for rapid development.
- Industrial-Grade Reliability: Engineered for harsh environments, these modules feature a wide operating temperature range of -40°C to +85°C, high-precision TCXO oscillators, and are compliant with CE, FCC, and RoHS standards.
- Ultra-Low Power Consumption: Optimized for battery-powered end-nodes, our low-power RF modules support multiple sleep modes and Wake-on-Radio (WOR) functionality to maximize field deployment lifespan.
1. How to Select LoRa Wireless Module?
You can quickly filter the most suitable LoRa module through the following 4 dimensions:
| Screening Dimension | Options & Corresponding Product Line |
|---|---|
| Interface Type | • UART Transparent → UART LoRa Series (plug-and-play, no RF development required)
|
| Frequency Band | • Sub-1GHz (433/470/868/915MHz) → Most long-range models, better wall penetration
|
| Transmission Range | • Short range (<3km) → E220, E53 and other low-power compact models
|
| Special Function | • Mesh self-organizing network → E52 LoRa Mesh Series
|
2. Detailed Parameter Comparison Tables
Table 1: UART Transparent LoRa Modules (Plug-and-Play)
Built-in MCU with mature transparent transmission firmware, directly connected via TTL UART, no RF driver development required. Ideal for rapid project validation and mass production.
| Series (Typical Model) | Chipset | Frequency Band | TX Power Range | Max LOS Distance | Air Data Rate | Supply Voltage | Interface | Key Features |
|---|---|---|---|---|---|---|---|---|
| E22 Series
|
SX1262 / SX1268 | 160–930MHz
|
22–30dBm | 5–10km | 0.3–62.5 kbps | DC 2.0–5.5V | UART (TTL) | AES encryption, LBT, air wake-up, deep sleep, wide industrial temperature |
| E32 Series
|
SX1276 / SX1278 | 160–931MHz
|
22–37dBm | 3–25km | 0.3–19.2 kbps | DC 3.3–5.5V | UART (TTL) | Classic high-reliability model, strong anti-interference, fixed-point & broadcast transmission |
| E220 Series
|
LLCC68 | 410–930MHz
|
20dBm | 2.5km | 0.3–62.5 kbps | DC 2.0–5.5V | UART (TTL) | Ultra-compact size, cost-effective, ultra-low standby power |
| E52 Mesh Series
|
— | 433/868/915MHz | 10–20dBm | 1.6–4km per hop | 7–62.5 kbps | DC 3.3–5.5V | UART (TTL) | Decentralized LoRa Mesh, multi-hop relay, self-healing, up to 46 nodes |
| E610 Series
|
EFR32FG23 | 433/868/915MHz | 20/30dBm | 1–2km (continuous)
|
High speed | DC 3.3–5.5V | UART (TTL) | High-speed continuous transmission, low latency, for real-time data scenarios |
Table 2: SPI RF Front-end LoRa Modules (Custom Development)
Pure RF transceiver controlled via SPI bus, suitable for developers who need to design custom protocols and firmware. E48/E49 Series UART transparent transmission versions are available in the same series.
| Series (Typical Model) | Chipset | Frequency Band | TX Power Range | Max LOS Distance | Supply Voltage | Interface | Key Features |
|---|---|---|---|---|---|---|---|
| E22/E32 SPI Series | SX1262 / SX1268 / SX1276/78 / LLCC68 | 160–930MHz | 20–33dBm | 3–8km | DC 1.8–3.7V | SPI | Flexible development, support LoRa/GFSK/FLRC modulation, industrial grade |
| E29/E290 Series | PAN3029 / PAN3060 | 410–510MHz | 20–30dBm | 5–16km | DC 2.0–3.6V | SPI | Domestic chip solution, DSSS, strong anti-interference, high cost performance |
| E48/E49 Series | CT230A / CT2310A | 410–510MHz / 850–930MHz | 20–30dBm | 2.5–5.5km | DC 2.0–3.6V | SPI | Domestic chip, mini package, suitable for embedded integration |
Table 3: SoC Integrated LoRa Modules (Secondary Development)
Integrate MCU and LoRa RF on a single chip, support user secondary development, reduce system size and BOM cost.
| Series (Typical Model) | Chipset | Frequency Band | TX Power | Max LOS Distance | Core | Supply Voltage | Key Features |
|---|---|---|---|---|---|---|---|
| E77 Series | STM32WLE5CCU6 | 410–510MHz / 850–930MHz | 22dBm | 3.5–6.5km | ARM Cortex-M4 | DC 2.0–3.6V | ST official solution, high integration, support LoRa and custom protocol |
| E78 Series | ASR6601 | 410–925MHz | 22dBm | 5.6km | ARM Cortex-M4 | DC 2.0–3.6V | Support LoRa & LoRaWAN dual protocol, low power, ideal for LoRaWAN nodes |
Table 4: 2.4GHz LoRa Modules
Operate in the 2.4GHz global ISM band, with higher data rate, suitable for scenarios requiring both distance and transmission speed.
| Series (Typical Model) | Chipset | Frequency Band | TX Power Range | Max LOS Distance | Interface | Key Features |
|---|---|---|---|---|---|---|
| E28 2.4G Series | SX1281 | 2400–2500MHz | 12 / 20 / 27dBm | 3–16km | UART / SPI | 2.4GHz LoRa modulation, high data rate, support ranging and FLRC mode |
Table 5: LoRaWAN Gateway Modules
Core RF front-end module for building LoRaWAN gateway base stations, support multi-channel parallel reception.
| Series (Typical Model) | Chipset | Frequency Band | TX Power | Max LOS Distance | Interface | Key Features |
|---|---|---|---|---|---|---|
| E106 Gateway Series | SX1302 | 433/470/868/915MHz | 27dBm | 5km | SPI | 8-channel LoRaWAN gateway chip, high sensitivity, support PoE power supply (baseboard) |
3. Quick Selection Steps
- Confirm interface type: Choose UART for fast deployment; choose SPI/SoC for custom development; choose gateway module for base station construction.
- Confirm frequency band: Choose Sub-1GHz for maximum transmission distance and penetration; choose 2.4GHz for global license-free band and higher data rate.
- Match transmission distance: Select the corresponding power grade according to actual communication distance and environmental occlusion.
- Match special functions: Select Mesh model for multi-point ad-hoc network; select LoRaWAN model for standard protocol networking.
- Verify environmental requirements: For harsh industrial sites, prioritize models with wide temperature range and ESD protection.
Ebyte’s LoRa solutions are the trusted choice for global engineers in Industrial Automation (PLC wireless links), Smart Agriculture (remote soil and irrigation monitoring), and Remote Sensing (smart utility metering and environmental data collection). Whether you require a high-power 30dBm transmitter or a compact SMD transceiver, our products deliver the industrial-grade stability required for mission-critical IoT ecosystems.
Ebyte E22-900T30D CE RoHs FCC Semtech SX1262 UART 10Km 30dBm 868Mhz 915Mhz DIP SX1262 LoRa Module
$10.60 – $11.60The Ebyte E22-900T30D is a high-power 30dBm LoRa UART module based on the Semtech SX1262 chip, engineered for ultra-long-range (10km) industrial telemetry across the 868/915MHz bands with full 3.3V/5V TTL...
EBYTE E22-400T33S LoRa Wireless Module 433MHz LoRa Spread Spectrum Module 33dBm 16KM IPEX/Stamp Hole LBT RSSI Antenna Module
$0.20 – $15.49The Ebyte E22-400T33S is a wireless serial port module (UART) based on SEMTECH's SX1268, working at 410.125 ～ 493.125MHz (default 433.125MHz),TTL level output, compatible with 3.3V and 5V IO port...
EBYTE E22-400T30D-V2 SX1268 433MHz 30dBm LoRa UART Long Range Module
$0.20 – $10.38E22-400T30D-V2 is a high-performance 1W (30dBm) LoRa wireless UART module powered by the Semtech SX1268 chip, delivering over 8km of line-of-sight range with exceptional -148dBm sensitivity and TCXO-stabilized frequency for...
EBYTE E32-900T30D-V8 LoRa Wireless Module 100mW 868/915MHz Support Air-Wake up DIP Long Range Wireless Module Transceiver
$11.70 – $12.99The Ebyte E32-900T30D is a wireless serial port module (TTL level) , transparent transmission mode, working in the 862~930MHz frequency band, using LoRa spread spectrum technology. At present, it has...
Ebyte E32-900M30S SX1276 Lora Wireless Module 868/915MHz 10KM Long Distance SPI Low Power Consumption SPI LoRa Spread Spectrum Module
$8.00 – $9.35The Ebyte E32-900M30S is a high-performance 1W (30dBm) LoRa module powered by the SX1276 chip, delivering an exceptional 10km long-range transmission in the 868/915MHz band, optimized for industrial-grade SPI hardware...
Ebyte E80-900M2213S Semtech multi-band LoRa LR1121 chip 22/13dBm 850-930M/2.4GHz LoRa dual-band wireless RF transceiver module
$6.20 – $7.49The Ebyte E80-900M2213S is a multi-band dual-frequency SMD LoRa wireless transceiver module based on the Semtech LoRa Connect LR1121 transceiver chip, delivering 22dBm (Sub-GHz, 5.6km) and 13dBm (2.4GHz, 2.6km) output...
EBYTE E22-400M22S SX1268 410-493MHz LoRa GFSK Wireless Module SX1268 433MHz Lora Module
$4.26 – $5.59EBYTE E22-400M22S uses the wireless module of Semtech SX1268 RF chip. Using multiple modulation methods such as LoRaTM and GFSK, its special LoRaTM modulation method increases the communication distance to...
EBYTE E220-400T30D LoRa LLCC68 433MHz Wireless Module 470MHz 30dBm Long Range 10km RSSI SMA-K DIP UART Transmitter Receiver
$0.20 – $8.30E220-400T30D adopts a new generation of LoRa spread spectrum technology and a wireless serial port module (UART) designed based on the LLCC68 chip solution. It has a variety of transmission...
Ebyte E80-900MBL-01 915Mhz USB LR1121 chip Sub-GHz 2.4GHz Satellite S-band LoRa wireless module development board evaluation Kit
$18.56The Ebyte E80-900MBL-01 series evaluation kit is designed to help users quickly evaluate Ebyte's new generation LoRa dual-band wireless module. The board is equipped with an STMicroelectronics general-purpose MCU STM32F103C8T6....
Ebyte E22-900MM22S SX1262 LoRa module 868/915MHz ultra small size Lora SMD module
$3.99E22-900MM22S is based on the new generation of LoRaTM radio frequency chip SX1262 produced by Semtech in the United States as the core of the independent research and development of...
EBYTE E220-400T22D LLCC68 Wireless Module RSSI ISM 433MHz 470MHz 22dBm LoRa Spread Spectrum DIP UART Interface SMA-K Antenna Low Power
$0.20 – $5.99E220-400T22D LoRa Wireless Module The E220-400T22D is a compact LoRa wireless module featuring Semtech's LLCC68 chip, offering 22dBm transmission power, 5km range, and UART interface for seamless IoT integration. Download...
EBYTE E22-230T30D-V2 SX1262 LoRa Wireless Module Low Power Consumption Long Rang
$10.19 – $11.19E22-230T30D-V2 is a new generation of LoRa wireless module. It is a wireless serial port module (UART) based on SEMTECH's radio frequency chip. Spread spectrum technology, TTL level output, compatible...
Ebyte E80-400M2213S Semtech multi-band LoRa LR1121 chip 21.5/13dBm 433M/2.4GHz LoRa dual-band wireless RF transceiver module
$6.20 – $7.60The EBYTE E80-400M2213S is a high-performance dual-band SMD LoRa transceiver module built on Semtech's third-generation LR1121 chip, supporting 410-493MHz, 2.4GHz, and satellite S-band frequencies with SPI control to deliver reliable...
Ebyte E52 Series LoRa MESH networking 433MHz 868MHz 915MHz spread spectrum Wireless serial port UART Self-routing network self-healing and Test suite
$0.40 – $14.90The Ebyte E52 Series is a versatile industrial-grade LoRa MESH networking transceiver module supporting 433MHz, 868MHz, and 915MHz bands, featuring UART transparent transmission, self-routing network auto-healing capabilities, and high-performance spread...
Ebyte E32-900T20S-V8 SX1276 LoRa Wireless Module 100mW 868/915MHz Support Air-Wake up SMD Long Range Wireless Module Date Transceiver
$5.99 – $7.59The Ebyte E32-900T20S is a wireless serial port module (TTL level) based on Semtech's LoRa solution, with transparent transmission mode, working in the 862~930MHz frequency band, and using LoRa spread...
Ebyte E220-400M33S 16km 33dBm LoRa Spread Spectrum Technology SPI RF Module 433/470MHz LLCC68 chip LoRa wireless module
$8.70E220-400M33S is based on the new generation of LoRaTM RF chip LLCC68 produced by Semtech. It is independently developed with a maximum power of 2W and is suitable for 433/470MHz...
